ORION HF320D-G3 Dual Node High Frequency Trading Server

Dual Node 'Haswell' Server Chassis with up to 4.5 GHz of Accelerated Performance

[OHF320D-G3]

More Image(s)

The latest in accelerated server technology. The HF320D-G3 features two accelerated server nodes in one 2RU chassis. Each accelerated up to 4.6 GHz, the nodes deliver high frequency, low latency performance in half the DC footprint of the HF320-G3.
Availability: In stock

For details on how to purchase the ORION HF320D-G3 Dual Node High Frequency Trading Server, please click the button below to send us your details and brief requirements. We can then quote you accordingly.

Details

The HF320D-G3 is based upon the single socket, 2U HF320-G3 system that’s long been available globally. The HF320D takes the same core acceleration technology from the HF320 and applies it with higher density.
Part No. OHF320D-G3
Manufacturer Ciara Technologies
End of Life? No
Rack Units 2
Height 89
Width 440
Depth 787
Weight [Kg] 22.70
CPU Socket(s) 2 (1 per node)
Compatible CPU(s) Intel® Core™ i7-5960X Processor Extreme Edition (8 cores, 20 MB) per node
Max CPU Clk Spd Accelerated up to 4.6 GHz (8 cores) with 43x/44x cache
CPU Cache 20 MB per node
Max # Thread(s) 16 per node
Max # Core(s) 8 per node
Memory Slot(s) 8 per Node
Memory Capacity Up to 64 GB per node
Memory Expansion 4 and 8 GB DDR4 2666 MHz UDIMM
Drive Bays (4) 2.5” SATA/SAS hot-swap drives + (1) M.2 or NVMe xed drive per node
Capacity Up to 4 TB per node
HDD Suitability Onboard Intel X99 Express chipset 6 Gbps SATA controller per node - Support Raid 0, 1, 5 and 10 Onboard LSI SAS3108 8 Ports 12 Gbps SAS/6 Gbps SATA controller per node - Support Raid 0, 1, 5, 6, 10
Supported OS Microsoft® Windows® 7 Professional, Windows 8 Pro;
Microsoft® Windows Server 2008 R2, Windows Server 2012 R2;
Linux RHEL 6.5 & 7, CentOS 6.5 & 7, SL 6.5 & 7
USB Port(s) (2) USB 3.0
PCI Slot(s) 1 x PCI-E 3.0 x16 (Full Height - Full Length - Double Width)
1 x PCI-E 3.0 x8 (Low Profile - Half Length)
1 x PCI-E 3.0 x8 (custom, for interconnect only) per node
or
2 x PCI-E 3.0 x8 (Full Height - Full Length - Single Width)
1 x PCI-E 3.0 x8 (Low Profile - Half Length)
1 x PCI-E 3.0 x8 (custom, for interconnect only) per node
LAN Socket(s) Intel I210AT, (2) GbE ports + (1) dedicated Management port per node Optional SolarFlare or Mellanox Low Latency single and dual 10 GbE ports
Graphics / GPU Aspeed AST2400 VGA
Optional Available in Canada, North America and International;
3 years parts and labour 9/5 Next business day on-site repair;
3 years parts and labour 24/7 Next business day on-site repair;
3 years parts and labour 24/7 4 hours on-site repair
Ciara ORION HF320D-G3 High Frequency Trading Server
