Fujitsu PRIMERGY RX2540 M2 Rack Server

The data center standard without compromise

[RX2540M2]

More Image(s)

FUJITSU Server PRIMERGY will give you the servers you need to power any workload and changing business requirements. As business processes expand so does the need for applications

Availability: In stock

Details

Intel E5-2600v4 boosts application performance

The FUJITSU Server PRIMERGY RX2540 M2 sets higher standards for usability, scalability and costefficiency. It is a 2U dual-socket rack server ideal for running enterprise applications, collaboration and messaging workloads as well as traditional databases. Plus, it substantially simplifies carrying out infrastructure-related tasks like server virtualization and consolidation.

As one of the key innovations, versatile performance is guaranteed by a new generation of processors. The PRIMERGY RX2540 M2 can be equipped with two of the latest Intel® Xeon® E5-2600 v4 processors with up to 44 cores.

Along with new DDR4 memory technology with up to 3 TB it boosts application performance to be able to cope with the increasing data growth and shortens time to business results. The modular design of the server offers excellent expandability with up to 24 disk drives, high storage density, DynamicLoM technology, up to 8 PCIe Gen 3 I/O expansion slots.

The DynamicLoM technology offers users the ability to individually adapt the current server network as well as the ability to change and thus meet future requirements without giving the server infrastructure a general overhaul. The PRIMERGY RX2540 M2 comes with two redundant hot-plug power supply units, offering up to 96% energy efficiency.

The Cool-safe® Advanced Thermal Design allows for operation in ambient temperatures of up to 40 °C/104 °F, optionally even up to 45°C/113°F. Both these features in line help to reduce operational expenses.

Features and Benefits

Main features	Benefits
Versatile performance to cope with data growth
Intel Xeon E5-2600 v4 product family with up to 22 cores per CPU Up to 1536 GB DDR4 memory and up to 8 PCIc slots Expanded scalability of up to 24x 2.5inch + 4 additional rear option 2.5-inch HDD or up to 12x 3.5-inch storage drives	Ready for the future and data growth scenarios with the performance of two processors – marking the standard of tomorrow with an increase in computing power of up to XX% compared to the previous generation (measured under SAP SD) DDR4 memory enables for higher bandwidth and lower consumption, optimized for data center tasks, enterprise applications but also collaboration & messaging solutions Flexible expandability and diverse options for storage devices permits for the integration of existing and new SSD and HDD as needed. Less today, more in future – or vice versa
Increased Energy Efficiency
Fujitsu’s Cool-safe® Advanced Thermal Design technology for a higher ambient temperature Redundant power supply units with 96% energy efficiency	Not only “greener”, also less expensive over time: Cost reduction due to lower energy consumption - both, air conditioning and the power supply itself Two hot-plug PSUs make it easy to maintain the running system and ensure a 99,997% uptime
Foundation for trust and security
Fujitsu ServerView Suite including tools for installation and deployment, permanent status monitoring and control BIOS, firmware and selected software are updated free of charge	The comprehensive tools of the Fujitsu ServerView Suite eases the administrators life Lifecycle investment protection: Updates are very important in a fast-paced world, especially considering cyber crime
Innovations simplifying management and freeing up IT resources
DynamicLoM to select the network connector of your choice - “plug&play-design” with 3 different port types, 3 different numbers of ports, and 2 different speeds and no need to upgrade to a new chip or new drivers. Customer-inspired design	DynamicLoM guarantees you the highest flexibility to integrate the server into your infrastructure – now and in future without overhauling the existing infrastructure Optimized for data centers and SMEs

Part No.	RX2540M2
Manufacturer	Fujitsu
End of Life?	No
Rack Units	2U
Height	8.6
Width	48.2
Depth	77
Weight [Kg]	25.00
CPU Socket(s)	1 - 2 x Intel® E5-2600 v4 Xeon® processor
Compatible CPU(s)	E5-2603v4 (6C/6T, 1.70GHz, TLC:15MB, Turbo: No, 6.4GT/s, 1866 MHz, 85W, AVX Base 1.70GHz); E5-2609v4 (8C/8T, 1.70GHz, TLC:20MB, Turbo: No, 6.4GT/s, 1866 MHz, 85W, AVX Base 1.70GHz); E5-2620v4 (8C/16T, 2.10GHz, TLC:20MB, Turbo: 2.30GHz, 8.0GT/s, 2133 MHz, 85W, AVX Base 1.80GHz, AVX Turbo 2.30GHz); E5-2623v4 (4C/8T, 2.60GHz, TLC:10MB, Turbo: 2.90GHz, 8.0GT/s, 2133 MHz, 85W, AVX Base 2.20GHz, AVX Turbo 2.90GHz); E5-2630Lv4 (10C/20T, 1.80GHz, TLC:25MB, Turbo: 2.00GHz, 8.0GT/s, 2133 MHz, 55W, AVX Base 1.30GHz, AVX Turbo 2.00GHz); E5-2630v4 (10C/20T, 2.20GHz, TLC:25MB, Turbo: 2.40GHz, 8.0GT/s, 2133 MHz, 85W, AVX Base 1.80GHz, AVX Turbo 2.40GHz); E5-2637v4 (4C/8T, 3.50GHz, TLC:15MB, Turbo: 3.60GHz, 9.6GT/s, 2400 MHz, 135W, AVX Base 3.20GHz, AVX Turbo 3.60GHz); E5-2640v4 (10C/20T, 2.40GHz, TLC:25MB, Turbo: 2.60GHz, 8.0GT/s, 2133 MHz, 90W, AVX Base 2.00GHz, AVX Turbo 2.60GHz); E5-2643v4 (6C/12T, 3.40GHz, TLC:20MB, Turbo: 3.60GHz, 9.6GT/s, 2400 MHz, 135W, AVX Base 2.80GHz, AVX Turbo 3.60GHz); E5-2650Lv4 (14C/28T, 1.70GHz, TLC:35MB, Turbo: 2.00GHz, 9.6GT/s, 2400 MHz, 65W, AVX Base 1.20GHz, AVX Turbo 1.70GHz); E5-2650v4 (12C/24T, 2.20GHz, TLC:30MB, Turbo: 2.50GHz, 9.6GT/s, 2400 MHz, 105W, AVX Base 1.80GHz, AVX Turbo 2.50GHz); E5-2660v4 (14C/28T, 2.00GHz, TLC:35MB, Turbo: 2.40GHz, 9.6GT/s, 2400 MHz, 105W, AVX Base 1.70GHz, AVX Turbo 2.40GHz); E5-2667v4 (8C/16T, 3.20GHz, TLC:25MB, Turbo: 3.50GHz, 9.6GT/s, 2400 MHz, 135W, AVX Base 2.60GHz, AVX Turbo 3.50GHz); E5-2680v4 (14C/28T, 2.40GHz, TLC:35MB, Turbo: 2.90GHz, 9.6GT/s, 2400 MHz, 120W, AVX Base 1.90GHz, AVX Turbo 2.80GHz); E5-2683v4 (16C/32T, 2.10GHz, TLC:40MB, Turbo: 2.60GHz, 9.6GT/s, 2400 MHz, 120W, AVX Base 1.70GHz, AVX Turbo 2.50GHz); E5-2690v4 (14C/28T, 2.60GHz, TLC:35MB, Turbo: 3.20GHz, 9.6GT/s, 2400 MHz, 135W, AVX Base 2.10GHz, AVX Turbo 2.90GHz); E5-2695v4 (18C/36T, 2.10GHz, TLC:45MB, Turbo: 2.60GHz, 9.6GT/s, 2400 MHz, 120W, AVX Base 1.70GHz, AVX Turbo 2.40GHz); E5-2697Av4 (16C/32T, 2.60GHz, TLC:40MB, Turbo: 3.10GHz, 9.6GT/s, 2400 MHz, 145W, AVX Base 2.20GHz, AVX Turbo 2.90GHz); E5-2697v4 (18C/36T, 2.30GHz, TLC:45MB, Turbo: 2.80GHz, 9.6GT/s, 2400 MHz, 145W, AVX Base 2.00GHz, AVX Turbo 2.70GHz); E5-2698v4 (20C/40T, 2.20GHz, TLC:50MB, Turbo: 2.70GHz, 9.6GT/s, 2400 MHz, 135W, AVX Base 1.80GHz, AVX Turbo 2.60GHz); E5-2699v4 (22C/44T, 2.20GHz, TLC:55MB, Turbo: 2.80GHz, 9.6GT/s, 2400 MHz, 145W, AVX Base 1.80GHz, AVX Turbo 2.60GHz);
Memory Slot(s)	24 (12 DIMMs per CPU, 4 channels with 3 slots per channel)
Memory Capacity	3TB
Drive Bays	PRIMERGY RX2540 M2 LFF 8 x 3.5-inch hot-plug SAS/ SATA 12 x 3.5-inch hot-plug SAS/ SATA PRIMERGY RX2540 M2 SFF 16 x 2.5-inch hot-plug SAS/ SATA 24 x 2.5-inch hot-plug SAS/ SATA
SATA Controller	Intel® C612, 1 x SATA channel for ODD
RAID Options	Fujitsu PRAID EP420i for SafeStore, RAID 5/6 Ctrl., SAS/SATA 12 Gbit/s, 8 ports int. RAID level: 0, 1, 10, 5, 50, 6, 60, 2 GB, Optional FBU based on LSI SAS3108 Fujitsu PRAID EP420i, RAID 5/6 Ctrl., SAS/SATA 12 Gbit/s, 8 ports int. RAID level: 0, 1, 10, 5, 50, 6, 60, 2 GB, Optional FBU based on LSI SAS3108 Fujitsu PRAID EP400i, RAID 5/6 Ctrl., SAS/SATA 12 Gbit/s, 8 ports int. RAID level: 0, 1, 10, 5, 50, 6, 60, 1 GB, Optional FBU based on LSI SAS3108 Fujitsu PRAID CP400i, RAID Ctrl., SAS/SATA 12 Gbit/s, 8 ports int. RAID level: 0, 1, 1E, 10, 5, 50, No FBU support
Supported OS	Microsoft® Hyper-V Server 2012 R2 Microsoft® Windows Server® 2012 R2 Datacenter Microsoft® Windows Server® 2012 R2 Standard Microsoft® Windows Server® 2012 R2 Essentials Microsoft® Windows Storage Server 2012 R2 Standard Microsoft® Hyper-V Server 2012 Microsoft® Windows Server® 2012 Datacenter Microsoft® Windows Server® 2012 Standard Microsoft® Windows Server® 2012 Essentials Microsoft® Windows Storage Server 2012 Standard VMware vSphere™ 6.0 VMware vSphere™ 5.5 SUSE® Linux Enterprise Server 12 SUSE® Linux Enterprise Server 11 Red Hat® Enterprise Linux 7 Red Hat® Enterprise Linux 6 Citrix® XenServer® Oracle® Linux 7 Oracle® Linux 6 Oracle® VM 3
USB Port(s)	USB 2.0 ports 5 x USB 2.0 (2x rear, 1x front external, 1x USB stick, 1x uSSD) // USB 3.0 ports 5 x USB 3.0 (2x front, 2x rear, 1x internal for backup device)
PCI Slot(s)	PCI-Express 3.0 x8 3 x Low profile (2nd processor required for slot 4) PCI-Express 3.0 x16 3 x Low profile (2nd processor required for slot 5 and 6)
LAN Controller(s)	DynamicLoM based on Emulex XE100 series. All supported features are described in relevant system configurator. PXE-Boot via LAN from PXE server, iSCSI / FCoE boot (also diskless).
Graphics Cards	NVIDIA® Quadro® M4000, 1344 cores, PCIe 3.0 x16, 4 x DisplayPort
Standard	3 years
Optional	Onsite warranty 9x5, Next Business Day Onsite Response Time 9x5, 4h Onsite Response Time 24x7, 4h Onsite Response Time
