The 1U Twin™ is designed to further satisfy the ever-increasing efficiency, density, and low-TCO demands of today's High Performance Computing (HPC) clusters, Data Center Front End Server and Virtualization, Cloud, and Hyperscale environments.
Availability: In stock
Details
The 1U Twin™ is an innovative 1U rackmount system supporting 2 compute nodes that is designed to increase processing density while reducing cost, energy and space when compared to traditional 1U rackmount servers. The 1U Twin™ supports up to four hot-swap 2.5" or two hot-swap 3.5" SATA3 drive bays per node for exceptional storage capacity. It also offers one x16 native PCI-Express 3.0 slot for highest non-blocking I/O bandwidth, 8 DIMM slots per node for up to 512GB of ECC LRDIMM DDR4 memory, onboard Gigabit Ethernet or Mellanox® ConnectX3 single-port 56Gbps InfiniBand to provide greatest networking connectivity, and redundant 1000-watt Titanium Level (96%+) power supplies for greatest efficiency.
| Part No. | SYS-5016Ti-TF |
|---|---|
| Manufacturer | SuperMicro |
| End of Life? | No |
| Rack Units | 1U |
| Height | 4.3 |
| Width | 43.7 |
| Depth | 70.5 |
| CPU Socket(s) | Intel® Xeon® X3400 series |
| Compatible CPU(s) | Intel® Xeon® L3400 series Intel® Core™ i3 Intel® Pentium® G6950 Intel® Celeron® G1101 |
| Memory Slot(s) | 6x 240-pin DDR3 DIMM slots |
| Drive Bays | 2x 3.5" SATA Hot-swap drive bays |
| SATA Controller | 6 SATA ports 2 SATA hard drives supported |
| RAID Options | RAID 0, 1 support (Windows) RAID 0, 1 support (Linux) |
| USB Port(s) | 2x USB rear ports 1x USB on-board 2x USB internal header (4 ports) Total 7 USB 2.0 Compliant |
| PCI Slot(s) | 1 (x16) PCI-E 2.0 |
| Serial Ports | 1x Fast UART 16550 serial port |
| LAN Socket(s) | 2x RJ45 LAN ports 1x RJ45 Dedicated IPMI LAN port |
| LAN Controller(s) | Dual Intel® 82574L Gigabit Ethernet Controllers |
| Graphics / GPU | Matrox G200eW 16MB DDR2 |
