Driven by German precision engineering and innovation, Fujitsu’s engineers maximized rack density in the datacenter while at the same time offering true workstation performance in only 1U. This allows customers in the automotive, aeronautic, energy as well as in the healthcare industry to benefit from faster time-to-market and reduced innovation cycles from the safety of the datacenter.
Availability: In stock
Details
| Part No. | c740 |
|---|---|
| Manufacturer | Fujitsu |
| End of Life? | No |
| Rack Units | 1 |
| Height | 44.45 |
| Width | 431 |
| Depth | 683 |
| Weight [Kg] | 13.00 |
| Specification | RoHS (Restriction of hazardous substances); WEEE (Waste electrical and electronic equipment); Microsoft Operating Systems (HCT / HCL entry / WHQL) |
| CPU Socket(s) | 1 |
| Compatible CPU(s) | Intel® Xeon® E5-2699v3 (18C, 2.30GHz, 45MB); Intel® Xeon® E5-2690v3 (12C, 2.60GHz, 30MB); Intel® Xeon® E5-2630v3 (8C, 2.40GHz, 20MB); Intel® Xeon® E5-2623v3 (4C, 3.00GHz, 10MB); Intel® Xeon® E5-2620v3 (6C, 2.40GHz, 15MB); Intel® Xeon® E5-2609v3 (6C, 1.90GHz, 15MB); Intel® Xeon® E5-2603v3 (6C, 1.60GHz, 15MB); Intel® Xeon® E5-1680v3 (8C, 3.20GHz, 20MB); Intel® Xeon® E5-1660v3 (8C, 3.00GHz, 20MB); Intel® Xeon® E5-1650v3 (6C, 3.50GHz, 15MB); Intel® Xeon® E5-1630v3 (4C, 3.70GHz, 10MB); Intel® Xeon® E5-1620v3 (4C, 3.50GHz, 10MB); Intel® Xeon® E5-1607v3 (4C, 3.10GHz, 10MB); Intel® Xeon® E5-1603v3 (4C, 2.80GHz, 10MB) |
| Max CPU Clk Spd | Up to 3.7 GHz |
| CPU Cache | Up to 45 MB |
| Max # Thread(s) | Up to 36 |
| Max # Core(s) | Up to 18 |
| Memory Slot(s) | 8 DIMM (DDR4) ECC |
| Memory Capacity | 256 GB @ 2133 MHz |
| Memory Expansion | 4 GB (1 module(s) 4 GB) DDR4, registered, ECC, 2,133 MHz, PC4-2133; 8 GB (1 module(s) 8 GB) DDR4, registered, ECC, 2,133 MHz, PC4-2133; 16 GB (1 module(s) 16 GB) DDR4, registered, ECC, 2,133 MHz, PC4-2133; 32 GB (1 module(s) 32 GB) DDR4, registered, ECC, 2,133 MHz, PC4-2133 |
| Drive Bays | 4x 2.5" and 1x 5.25" |
| Capacity | 4.8 TB |
| HDD Suitability | SATA III; SSD; SSD PCIe; SAS; SATA DOM |
| RAID Options | RAID 5/6 Ctrl. 12 Gbit/s 8 ports int.; RAID 0/1 Ctrl. 12 Gbit/s 8 ports int.; RAID 0/1 Ctrl. 6 Gbit/s 8 ports int. |
| Supported OS | Windows 7, 8, 8.1 64-bit; Linux |
| USB Port(s) | 5x USB Total, 2x USB 2.0, 3x USB 3.0 |
| PCI Slot(s) | 1 Full height PCIe 3.0 x8; 1x Full height double slot PCIe 3.0 x16 or 2x Full height single slot PCIe 3.0 x16 |
| Serial Ports | 1 (optional via slot bracket) |
| LAN Socket(s) | 2x Built-in 10/100/1,000 MBit/s Intel® I217LM and Intel® I210AT |
| Graphics Cards | Ultra-high-end 3D: AMD FirePro™ W9100, 16 GB, 2816 stream processors, PCIe x16, 6x miniDP, 6x miniDP/DP Adapter; Ultra-high-end 3D: NVIDIA® Quadro® K6000, 12 GB, 2,880 cores, PCIe x16, 1x Dual Link DVI-I, 1x Dual Link DVI-D, 2x DisplayPort; Ultra-high-end 3D: NVIDIA® Quadro® K5200, 8 GB, 2304 cores, PCIe x16, 1x Dual Link DVI-I, DVI-D, 2x DisplayPort; High-end 3D: AMD FirePro™ W7100, 8 GB, PCIe x16, 4 x DisplayPort; High-end 3D: NVIDIA® Quadro® K4200, 4 GB, 1344 cores, PCIe x16, 1x Dual Link DVI-I, 2x DisplayPort; Midrange 3D: NVIDIA® Quadro® K2200, 4 GB, 640 cores, PCIe x16, 1x Dual Link DVI-I, 2x DisplayPort; Midrange 3D: AMD FirePro™ W5100 , 4 GB, PCIe x16, 4 x DisplayPort; Entry 3D: AMD FirePro™ W4100, 2 GB, 512 stream processors, PCIe x16, 4x miniDP, 4x miniDP/DP Adapter; Entry 3D: NVIDIA® Quadro® K620, 2 GB, 384 cores, PCIe x16, 1x Dual Link DVI-I, 1x DisplayPort; Entry 3D: AMD FirePro™ W2100, 2 GB, 320 stream processors, PCIe x16, 2x DisplayPort; Entry 3D: NVIDIA® Quadro® K420, 1 GB, 192 cores, PCIe x16, 1x Dual Link DVI-I, 1x DisplayPort; Professional 2D: NVIDIA® NVS™ 510, 2 GB, 16 cores, PCIe 2.0 x16, 4x miniDP, 4x miniDP/DP Adapter; Professional 2D: NVIDIA® NVS™ 315, 1 GB, 48 cores, PCIe 2.0 x16, 2x LFH59 (DP/DVI-I); GPU computing card: NVIDIA® Tesla® K20, 5 GB, 2,496 cores, PCIe x16; GPU computing card: NVIDIA® GRID™ K2 8GB, 8 GB, 3,072 cores, PCIe x16; Remote Graphics: CELSIUS RemoteAccess Dual Card, PCIe x1, 2x miniDP, PCoIP; Remote Graphics: CELSIUS RemoteAccess Quad Card, PCIe x1, 4x miniDP, PCoIP; Coprocessor: Intel® Xeon Phi™ Coprocessor 3120A, PCIe x16; Coprocessor: Intel® Xeon Phi™ Coprocessor 5110P, PCIe x16 |
| Standard | 3 years (depending on country) Onsite Service (for countries within region FTS CEMEA&I, for all other countries depending on local regulations, minimum: 3 years material warranty) |
| Optional | 9x5, Onsite Response Time: Next Business Day |
