Details
Combines affordable price-level with:
- High performance.
- Rich data safety functionality.
- Enterprise proven capabilities already in entry-level storage.
- Easy to install, configure, operate and maintain.
Fits perfectly to:
- Storage consolidation starters & virtualization newcomers.
- Medium capacity requirements with moderate growth rates.
- Comes with a richly featured management suite at no extra costs.
- Single point administration.
- Easy and efficient operation.
Manufacturer | Fujitsu |
---|---|
Part No. | FTS:ET06S22AG |
Width | 483 |
Height | 88 |
Depth | 650 |
Weight [Kg] | 35.00 |
Rack Units | 2 U, or 4 U with Storage Attachment (3.5") |
Drive Bays | 24x 2.5" or; 24x 3.5" with Drive Enclosure |
Capacity | 21.6 TB or 72.0 TB (2.5 or 3.5" Models) |
HDD Suitability | 3.5" SAS 600 GB/450 GB/300 GB (15,000 rpm); 3.5" Nearline SAS 3 TB/2 TB/1 TB (7,200 rpm); 2.5" SAS 900 GB/600 GB/450 GB/300 GB (10,000 rpm) |
Cache Backup | 1 or 2 GB (Single or Dual Controller) |
Host Interface / Link Speeds | Serial Attached SCSI (3 Gbit/s) |
Supported OS | Microsoft® Windows Server®2008 Standard, Enterprise and Datacenter (32-bit) (64-bit) including R2. |
LAN Socket(s) | Ethernet (1000 Base-T / 100 Base-TX / 10 Base-T) |
RAID Options | 0, 1, 1+0, 5, 5+0, 6 |
Fujitsu’s second generation of ETERNUS DX disk storage systems, ETERNUS DX S2, are The Flexible Data Safe for Dynamic Infrastructures. Enterprise-proven capabilities protect data assets across all types of IT infrastructure. Redundant components, RAID protection and build-in data protection provide the highest system reliability to ensure business continuity is maintained.
ETERNUS DX S2 models are comprehensive disk storage platforms with superior scalability to address the demands of intensive data growth and highest performance. Free choice of modular disk storage and state-of-the-art connectivity across the entire model range delivers maximum configuration flexibility allowing choice in performance and TCO.
The unified ETERNUS SF storage management software enables single point administration, easy data protection and efficient operation across the entire ETERNUS DX range. In virtualized IT environments in particular, ETERNUS SF perfectly integrates the powerful ETERNUS DX disk storage with minimal administration effort.
