Fujitsu PRIMERGY CX400 M1 Scale-Out Server

PRIMERGY CX400 M1 gives 8 Xeon E5-2600v4 sockets, in just 2RU

FUJITSU Server PRIMERGY systems provide the most powerful and flexible data center solutions for companies of all sizes, across all industries and for any type of workload.

This includes expandable PRIMERGY tower servers for remote and branch offices, versatile rack-mount servers, compact and scalable blade systems, as well as density-optimized scale-out servers.

cutting operational cost and complexity

They convince by business proven quality with a wide range of innovations, highest efficiency cutting operational cost and complexity, and provide more agility in daily operations in order to turn IT faster into a business advantage.

hyper-converged and high performance

The FUJITSU Server PRIMERGY CX scale-out systems are the ideal basis for cloud, hyper-converged and high performance computing solutions.

They provide data centers as well as branch offices with massive computing power for virtualized environments, complex calculations as well as consolidation and high-availabilty scenarios.

providing the very highest performance and energy efficiency

The Fujitsu Server PRIMERGY CX400 M1 helps to meet the immense challenges now facing companies as well as research and development institutions.

The system with only 2 height units contains up to four server nodes, 8 Intel® Xeon® processors and 64 DDR4 memory DIMMs, thus providing the very highest performance and energy efficiency levels.

Enhanced scalability, start your building block infrastructure

The scale-out system can be perfectly adapted for a wide range of applications thanks to its high degree of modularity. When requirements change, additional server nodes, co-processor cards or hard disks can just be added.

In comparison to conventional rack servers the PRIMERGY CX400 M1 wins through thanks to its double server density and low hardware and operating costs. The system is thus an ideal replicable component in order to implement large scale-out solutions.

New condensed 4in2U server density

• The PRIMERGY CX400 M1 features up to 4 half-wide dual socket server nodes plus up to 24 storage drives in a single 2U enclosure
• 50% less rack space in comparison with standard rack servers enables to scale-out more smartly
• Higher server density results in more performance per rack unit (4 servers, 8 processors, 24 drives and 64 DIMMs in 2U chassis)

Server nodes for every scenario

• Different dual socket server nodes featuring latest Intel® Xeon® processor E5-2600 v3 product family
• Standard server node, 16 DIMMs (1U)
• Enhanced HPC node with up to two GPGPU or co-processor cards, 16 DIMMs (2U)
• Different types of server nodes allow for best match to particular scale-out solution stacks
• Latest Intel® Xeon® processor E5-2600 v3 product family CPUs for top performance and lower energy budgets

Full compliance to conventional datacenter environments

• The PRIMERGY CX400 M1 complies to conventional datacenter front-to-back airflow and cooling and standard 19" industry rack infrastructure and applications
• Easy rack-wide team play with already existing datacenter infrastructure lowers overall investment

Variable local storage

• Up to 24x 2.5" hot-plug storage drives (HDD, SSD, PCIe) for 4 server nodes
• Flexibility of drive choice, adaptable to any demand
• Up to 6 drives can be assigned to a single server node to suit even high storage demands

Easy serviceability

• Hot-plug for server nodes, power supplies and disk drives enables enhanced availability and easy serviceability
• Each single server can be serviced without affecting the other nodes in the chassis.
