The PRIMERGY MX130 S1 micro server is just what micro businesses need. The MX130 S1 is a solid platform on which to base your file, web or print services. It increases your company’s potential by offering server reliability and efficiency at a rock-bottom price.
Availability: In stock
Details
The running costs and environmental impact are micro too, thanks to the 85% efficient power supply unit. If you think
of servers as complicated, space-eating machines, then think again. The MX130 S1 comes in a classic desktop chassis which can also be used vertically. And, best of all, it’s so silent you will hardly know it’s there. PRIMERGY MX130 S1 the micro server for macro results.
Part No. | M1301SC040GB |
---|---|
Manufacturer | Fujitsu |
Height | 100 |
Width | 340 |
Depth | 380 |
Weight [Kg] | 10.00 |
CPU Socket(s) | 1 [AMD 785G Chipset] |
Compatible CPU(s) | AMD Sempron™ 140 (1C, 2.7 GHz, SLC: 1 MB); AMD Athlon™ II X2 220 (2C, 2.8 GHz, SLC: 1 MB); AMD Athlon™ II X2 255 (2C, 3.1 GHz, SLC: 2 MB); AMD Phenom™ II X6 1035T (6C, 2.6 GHz, SLC: 9 MB) |
Max CPU Clk Spd | Up to 3.1 GHz |
CPU Cache | Up to 9 MB SLC |
Max # Core(s) | 1, 2 or 6 per CPU |
Memory Slot(s) | 4 (DDR3) |
Memory Capacity | 16 GB |
Drive Bays | 3 x (2x 3.5-inch and 1x 5.25-inch - all non hot-plug SATA; in each of the 2x 3.5” bays, it is possible to fit up to 2x 2.5” HDDs). |
Capacity | Up to 4.0 TB |
HDD Suitability | SATA, 500 GB, 7200 rpm, 3.5-inch, economic; HDD SATA II, 2000 GB, 7200 rpm, 3.5-inch, business critical; HDD SATA II, 1000 GB, 7200 rpm, 3.5-inch, business critical; HDD SATA II, 500 GB, 7200 rpm, 3.5-inch, business critical; HDD SATA II, 250 GB, 7200 rpm, 3.5-inch, business critical; HDD SATA II, 250 GB, 7200 rpm, 3.5-inch; HDD SATA II, 2x 500 GB, 5400 rpm, 2.5-inch, economic; HDD SATA II, 2x 320 GB, 5400 rpm, 2.5-inch, economic; HDD SATA II, 2x 160 GB, 5400 rpm, 2.5-inch, economic |
SATA Controller | SATA2 |
RAID Controller | 6 port SATA with RAID 0/1/10 for HDDs |
Supported OS | Microsoft® Microsoft® Hyper-V™ Server 2008 R2 Microsoft® Windows Server® 2008 R2 Standard Microsoft® Windows Server® 2008 R2 Foundation Microsoft® Windows® Small Business Server Essentials 2011 |
USB Port(s) | 12 (2 x front, 6 x back, 4 x internal) |
PCI Slot(s) | 2 x (190 mm) low profile |
Serial Ports | 1 x RS232 |
LAN Socket(s) | BCM 57780, 10/100/1000 Mbit/s Ethernet, PXE-Boot by LAN via PXE-Serve |
LAN Controller(s) | BCM 57780 |
Bandwidth | 1 GbE |
Graphics / GPU | 1 (Dual link DVI-I) ATI Radeon® HD 4200 (up to 2811MB) on board |
Standard | 1yr Onsite Service |
