FUJITSU PRIMERGY TX1320 M2 Tower Server

For small environments with high demands

[S26361-K1563-V201]

More Image(s)

The FUJITSU Server PRIMERGY TX1320 M2 is the perfect server for environments where space, full server functionality and silent operation are crucial.
Availability: In stock

For details on how to purchase the FUJITSU PRIMERGY TX1320 M2 Tower Server, please click the button below to send us your details and brief requirements. We can then quote you accordingly.

Details

the perfect server for environments where space, full server functionality and silent operation are crucial

The ultra-compact tower server is an excellent choice for retail premises, branch offices, or in other contexts where strict legal controls apply.

With full server management capabilities the system can easily be integrated into existing IT infrastructures or administered from afar.

Despite its size the PRIMERGY TX1320 M2 features Intel® Xeon® processor E3 family performance, up to six storage drives and supports an optional backup device. This unique combination makes it ideal for demanding environments where space is scarce.

Cost effective performance

  • Intel® Xeon® processor E3 v5 family with up to 4 cores
  • Up to 64 GB DDR4 ECC memory (4 DIMMs) and 4 PCIe slots
  • Low energy consumption - full server performance
  • Provides more than enough performance for small and medium-sized businesses and branch offices
  • Ideal for all classic server tasks, such as file, print, web or office applications
  • Good for the energy bill and for the environment

Support for special solutions

  • Ultra-small form factor fits everywhere – in either tower or desktop position
  • Low noise emissions through optimized air flow and Fujitsu's Cool-safe® technology
  • Space-saving: ideal for small offices, at point of sales or in racks for telephone systems
  • Silent operation for use in offices or showrooms
  • So small and silent that it might even be placed on the desk

Full server management features & easy accesibility

  • Fujitsu ServerView Suite including tools for installation and deployment, permanent status monitoring and control
  • Screwless chassis, hot-plug 2.5-inch and “Easy Rails” for 3.5-inch storage disks
  • Small server but full server management features: The comprehensive tools of the Fujitsu ServerView Suite eases the administrators life
  • Easy, fast and comfortable access to the interior of the server, the hard disks and PCI slots
Part No. S26361-K1563-V201
Manufacturer Fujitsu
End of Life? No
Preceeded By TX1320 M1
Succeeded By TX1320 M3
Height 340
Width 98
Depth 399
Weight [Kg] 10.00
CPU Socket(s) 1 x Intel® Pentium® processor / Intel® Core™ i3 processor / Intel® Xeon® processor E3-1200 v5 product family
Compatible CPU(s) G3900 (2C, 2.80 GHz, TLC: 2 MB, T: No, 2,133 MHz, 51 W);
i3-6100 (2C, 3.70 GHz, TLC: 3 MB, T: No, 2,133 MHz, 51 W);
G4400 (2C, 3.30 GHz, TLC: 3 MB, T: No, 2,133 MHz, 54 W);
E3-1220v5 (4C, 3.00 GHz, TLC: 8 MB, T: 3.50 GHz, 2,133 MHz, 80 W);
E3-1225v5 (4C, 3.30 GHz, TLC: 8 MB, T: 3.70 GHz, 2,133 MHz, 80 W);
E3-1230v5 (4C, 3.40 GHz, TLC: 8 MB, T: 3.80 GHz, 2,133 MHz, 80 W);
E3-1240Lv5 (4C, 2.10 GHz, TLC: 8 MB, T: 3.20 GHz, 2,133 MHz, 25 W);
E3-1240v5 (4C, 3.50 GHz, TLC: 8 MB, T: 3.90 GHz, 2,133 MHz, 80 W);
E3-1260Lv5 (4C, 2.90 GHz, TLC: 8 MB, T: 3.90 GHz, 2,133 MHz, 45 W);
E3-1270v5 (4C, 3.60 GHz, TLC: 8 MB, T: 4.00 GHz, 2,133 MHz, 80 W);
E3-1280v5 (4C, 3.70 GHz, TLC: 8 MB, T: 4.00 GHz, 2,133 MHz, 80 W)
Max CPU Clk Spd Up to 4 GHz (Turbo, cores disabled)
CPU Cache Up to 8 MB per CPU
Max # Thread(s) Up to 8 Threads per CPU
Max # Core(s) Up to 4 per CPU
Memory Slot(s) 4
Memory Capacity 4 GB - 64 GB
Memory Expansion Mix and match possible; with dual channel operation better performance (2 modules with equal capacity necessary).
Single channel (1 module) configuration possible
Drive Bays 3.5-inch non hot-plug;
2.5-inch hot-plug SAS/SATA
HDD Suitability Not upgradeable in the field.
SATA Controller Intel® C236, 2 ports used for accessible drives
RAID Controller Optionally integrated RAID 0/1 or RAID 5/6 controller for SAS base units (occupies one PCIe slot).
Supported OS Microsoft® Hyper-V Server 2016;
Microsoft® Windows Server® 2016 Datacenter;
Microsoft® Windows Server® 2016 Standard;
Microsoft® Windows Server® 2016 Essentials;
Microsoft® Windows Storage Server 2016 Standard;
Microsoft® Hyper-V Server 2012 R2;
Microsoft® Windows Server® 2012 R2 Datacenter;
Microsoft® Windows Server® 2012 R2 Standard;
Microsoft® Windows Server® 2012 R2 Essentials;
Microsoft® Windows Server® 2012 R2 Foundation;
Microsoft® Windows Storage Server 2012 R2 Standard;
Microsoft® Hyper-V Server 2012;
Microsoft® Windows Server® 2012 Datacenter;
Microsoft® Windows Server® 2012 Standard;
Microsoft® Windows Server® 2012 Essentials;
Microsoft® Windows Server® 2012 Foundation;
Microsoft® Windows Storage Server 2012 Standard;
Microsoft® Hyper-V™ Server 2008 R2;
Microsoft® Windows Server® 2008 R2 Datacenter;
Microsoft® Windows Server® 2008 R2 Enterprise;
Microsoft® Windows Server® 2008 R2 Standard;
Microsoft® Windows Server® 2008 R2 Foundation;
VMware vSphere™ 6.5;
VMware vSphere™ 6.0;
VMware vSphere™ 5.5;
SUSE® Linux Enterprise Server 12;
SUSE® Linux Enterprise Server 11;
Red Hat® Enterprise Linux 7;
Red Hat® Enterprise Linux 6;
Oracle® Linux 6
USB Port(s) 3 (2x external rear, 1x internal) (USB 3.0);
7 (4x external rear, 2x external front, 1x internal for UFM, no USB wakeup supported (USB 2.0)
PCI Slot(s) PCI-Express 3.0 x1 (mech.x4)
1 x Low profile
PCI-Express 3.0 x4
1 x Low profile
PCI-Express 3.0 x8
2 x Low profile
Serial Ports 1 serial RS-232-C
LAN Socket(s) 2 x1 Gb/s Ethernet; RJ45
LAN Controller(s) Intel® i210 onboard
2 x 10/100/1000 Mbit/s Ethernet
iSCSI, PXE-Boot and WoL are supported
Graphics / GPU 1 analog graphics interface derived from iRMC (up to 1600x1200 or 1920x1080 at 16bpp)
Graphics Cards NVIDIA® NVS™315 LP, PCIe x16, 2x DVI/VGA
Standard 1 year Onsite Service
Optional X - Globally available in major business areas:
9x5, Next Business Day Onsite Response Time
9x5, 4h Onsite Response Time (depending on country)
24x7, 4h Onsite Response Time (depending on country)
