The Fujitsu server Primergy RX2530 M2 is a rack server that provides high performance, expandability and energy efficiency in a 1U space saving housing.
Availability: In stock
Details
| Part No. | RX2530M2 |
|---|---|
| Manufacturer | Fujitsu |
| End of Life? | No |
| Rack Units | 1U |
| Height | 4.3 |
| Width | 48.3 |
| Depth | 77 |
| Weight [Kg] | 16.00 |
| CPU Socket(s) | 1 - 2 x Intel® Xeon® E5-2600 v4 processor |
| Compatible CPU(s) | E5-2603v4 (6C/6T, 1.70GHz, TLC:15 MB, Turbo:No, 6.4GT/s, 1,866MHz, 85W, AVX Base 1.70GHz); E5-2609v4 (8C/8T, 1.70GHz, TLC:20 MB, Turbo:No, 6.4GT/s, 1,866MHz, 85W, AVX Base 1.70GHz); E5-2620v4 (8C/16T, 2.10GHz, TLC:20 MB, Turbo:2.30GHz, 8.0GT/s, 2,133MHz, 85W, AVX Base 1.80GHz, AVX Turbo 2.30GHz); E5-2623v4 (4C/8T, 2.60GHz, TLC:10 MB, Turbo:2.90GHz, 8.0GT/s, 2,133MHz, 85W, AVX Base 2.20GHz, AVX Turbo 2.90GHz); E5-2630Lv4 (10C/20T, 1.80GHz, TLC:25 MB, Turbo:2.00GHz, 8.0GT/s, 2,133MHz, 55W, AVX Base 1.30GHz, AVX Turbo 2.00GHz); E5-2630v4 (10C/20T, 2.20GHz, TLC:25 MB, Turbo:2.40GHz, 8.0GT/s, 2,133MHz, 85W, AVX Base 1.80GHz, AVX Turbo 2.40GHz); E5-2637v4 (4C/8T, 3.50GHz, TLC:15 MB, Turbo:3.60GHz, 9.6GT/s, 2,400MHz, 135W, AVX Base 3.20GHz, AVX Turbo 3.60GHz); E5-2640v4 (10C/20T, 2.40GHz, TLC:25 MB, Turbo:2.60GHz, 8.0GT/s, 2,133MHz, 90W, AVX Base 2.00GHz, AVX Turbo 2.60GHz); E5-2643v4 (6C/12T, 3.40GHz, TLC:20 MB, Turbo:3.60GHz, 9.6GT/s, 2,400MHz, 135W, AVX Base 2.80GHz, AVX Turbo 3.60GHz); E5-2650Lv4 (14C/28T, 1.70GHz, TLC:35 MB, Turbo:2.00GHz, 9.6GT/s, 2,400MHz, 65W, AVX Base 1.20GHz, AVX Turbo 1.70GHz); E5-2650v4 (12C/24T, 2.20GHz, TLC:30 MB, Turbo:2.50GHz, 9.6GT/s, 2,400MHz, 105W, AVX Base 1.80GHz, AVX Turbo 2.50GHz); E5-2660v4 (14C/28T, 2.00GHz, TLC:35 MB, Turbo:2.40GHz, 9.6GT/s, 2,400MHz, 105W, AVX Base 1.70GHz, AVX Turbo 2.40GHz); E5-2667v4 (8C/16T, 3.20GHz, TLC:25 MB, Turbo:3.50GHz, 9.6GT/s, 2,400MHz, 135W, AVX Base 2.60GHz, AVX Turbo 3.50GHz); E5-2680v4 (14C/28T, 2.40GHz, TLC:35 MB, Turbo:2.90GHz, 9.6GT/s, 2,400MHz, 120W, AVX Base 1.90GHz, AVX Turbo 2.80GHz); E5-2683v4 (16C/32T, 2.10GHz, TLC:40 MB, Turbo:2.60GHz, 9.6GT/s, 2,400MHz, 120W, AVX Base 1.70GHz, AVX Turbo 2.50GHz); E5-2690v4 (14C/28T, 2.60GHz, TLC:35 MB, Turbo:3.20GHz, 9.6GT/s, 2,400MHz, 135W, AVX Base 2.10GHz, AVX Turbo 2.90GHz); E5-2695v4 (18C/36T, 2.10GHz, TLC:45 MB, Turbo:2.60GHz, 9.6GT/s, 2,400MHz, 120W, AVX Base 1.70GHz, AVX Turbo 2.40GHz); E5-2697Av4 (16C/32T, 2.60GHz, TLC:40 MB, Turbo:3.10GHz, 9.6GT/s, 2,400MHz, 145W, AVX Base 2.20GHz, AVX Turbo 2.90GHz); E5-2697v4 (18C/36T, 2.30GHz, TLC:45 MB, Turbo:2.80GHz, 9.6GT/s, 2,400MHz, 145W, AVX Base 2.00GHz, AVX Turbo 2.70GHz); E5-2698v4 (20C/40T, 2.20GHz, TLC:50 MB, Turbo:2.70GHz, 9.6GT/s, 2,400MHz, 135W, AVX Base 1.80GHz, AVX Turbo 2.60GHz); E5-2699v4 (22C/44T, 2.20GHz, TLC:55 MB, Turbo:2.80GHz, 9.6GT/s, 2,400MHz, 145W, AVX Base 1.80GHz, AVX Turbo 2.60GHz); |
| Memory Slot(s) | 24 (12 DIMMs per CPU, 4 channels with 3 slots per channel) |
| Memory Capacity | 8 GB - 1.536 GB |
| Drive Bays | up to 8 x 2.5-inch, 10 x 2.5-inch or 4 x 3.5-inch baseunit
Base unit specifics up to 4x 3.5” (LFF) hot plug drives (SAS/SATA) up to 4x 2.5” (SFF) hot plug drives (SAS/SATA); option for upgrade to 8x 2.5” (SFF) hot plug drives up to 10x 2.5” (SFF) hot plug drives (SAS/SATA); therein up to 4x bays are prepared for 2.5” PCIe Flash SSD |
| SATA Controller | Intel® C612, 1 x SATA channel for ODD |
| Supported OS | Microsoft® Hyper-V Server 2012 R2 Microsoft® Windows Server® 2012 R2 Datacenter Microsoft® Windows Server® 2012 R2 Standard Microsoft® Windows Server® 2012 R2 Essentials Microsoft® Windows Storage Server 2012 R2 Standard Microsoft® Hyper-V Server 2012 Microsoft® Windows Server® 2012 Datacenter Microsoft® Windows Server® 2012 Standard Microsoft® Windows Server® 2012 Essentials Microsoft® Windows Storage Server 2012 Standard VMware vSphere™ 6.0 VMware vSphere™ 5.5 SUSE® Linux Enterprise Server 12 SUSE® Linux Enterprise Server 11 Red Hat® Enterprise Linux 7 Red Hat® Enterprise Linux 6 Citrix® XenServer® Oracle® Linux 7 Oracle® Linux 6 Oracle® VM 3 |
| USB Port(s) | USB 2.0 ports 1 x USB 2.0 (1x rear) // USB 3.0 ports 5 x USB 3.0 (2x front, 2x rear, 1x internal) - for base unit with 10x 2.5” drives 1x USB2.0 at front only |
| PCI Slot(s) | PCI-Express 3.0 x8 2 x Low profile PCI-Express 3.0 x16 2 x Low profile (2nd processor required for slot 4); 1x16 if fh slot selected |
| LAN Controller(s) | DynamicLoM based on Emulex XE100 series. 2x 1Gbit/s Dynamic LoM#4x 1Gbit/s Dynamic LoM#2x 10Gbit/s 10GBASE-T Dynamic LoM#2x 10Gbit/s SFP+ Dynamic LoM. |
| Graphics / GPU | 2 x VGA (thereof 1x front optional - not for base unit with 10x 2.5” drives) |
