Fujitsu PRIMERGY TX150 S7 SME Tower Server
The one-processor tower server - maximised!
[T1507SX050IN]The PRIMERGY TX150 S7: the right system for SMEs or non-mission-critical decentralized infrastructures where the main focus is on expandability and availability. The expandability and availability come from the 6 expansion slots (5 of which PCIe Gen 2) and up to 8x 2.5 hot-plug hard disks. Increase the system’s availability and energy efficiency through the use of optional redundant power supplies boasting up to 89% energy efficiency. The TX150 S7 also offers up to the latest generation Intel® Xeon® processor 3400 series single processor platform, delivering excellent energy-efficient performance at an attractive price. The PRIMERGY TX150 S7: the single socket tower server – maximised!
Details
PRIMERGY TX tower servers are ideal for use in SMEs or branch offices. They increase operational efficiency by providing rock solid, record-breaking, energy efficient performance. That performance is built on 20-years of pioneering work in Green IT. As a customer, you benefit from a reduction in your organization’s environmental impact and lower running costs. The reliability is proven by testing the machines through 5000 boot cycles – far more than other vendors do. PRIMERGY TX servers are also easy to manage via the PRIMERGY ServerView Suite, reducing IT admin workload and costs. Plus, tower to rack conversion kits are available for most TX systems, ensuring investment protection.
Main Features
- By combining the latest Intel® mono-processor platform and SAS 2.0 hard disks with Fujitsu’s engineering, you can get great performance with low energy consumption.
- High performance and energy efficiency.
- Hot plug hard disks: choose between max. 4x 3.5 or max. 8x 2.5”. Power supply units: choose between standard or redundant.
- High availability options to suit your business.
- Up to 32GB of RAM and 6 expansion slots (5 of which second generation PCIe slots).
- High expandability - the TX150 S7 grows with your business.
- The PRIMERGY TX150 S7 can be integrated into a rack infrastructure with the tower to rack conversion kit.
- High versatility - increases your investment’s lifetime.
- The green touch points, the system ID card and the customer selfservice module make servicing the TX150 S7 easier.
- High serviceability - saves your time.
Part No. | T1507SX050IN |
---|---|
Manufacturer | Fujitsu |
Height | 444 or 220 |
Width | 205 or 482 |
Depth | 584 or 570 |
Weight [Kg] | 28.00 |
CPU Socket(s) | 1 x Intel® Core™ i3 / Pentium® / Xeon® L3400 / Xeon® X3400 |
Compatible CPU(s) | Intel® Core™ i3-540 (2C/4T, 3.06 GHz, TLC: 4 MB); Intel® Core™ i3-550 (2C/4T, 3.20 GHz, TLC: 4 MB); Intel® Core™ i3-560 (2C/4T, 3.33 GHz, TLC: 4 MB); Intel® Pentium® G6950 (2C, 2.80 GHz, TLC: 3 MB); Intel® Xeon® L3406 (2C/4T, 2.26 GHz, TLC: 4 MB); Intel® Xeon® L3426 (4C/8T, 1.86 GHz, TLC: 8 MB); Intel® Xeon® X3430 (4C/4T, 2.40 GHz, TLC: 8 MB); Intel® Xeon® X3440 (4C/8T, 2.53 GHz, TLC: 8 MB); Intel® Xeon® X3450 (4C/8T, 2.66 GHz, TLC: 8 MB); Intel® Xeon® X3470 (4C/8T, 2.93 GHz, TLC: 8 MB); Intel® Xeon® X3480 (4C/8T, 3.06 GHz, TLC: 8 MB) |
Max CPU Clk Spd | Up to 3.33 GHz |
CPU Cache | 3, 4 or 8 MB |
Max # Thread(s) | 1, 4 or 8 per CPU |
Max # Core(s) | 2 or 4 per CPU |
Memory Slot(s) | 6 |
Memory Capacity | 32 GB |
Drive Bays | 4x 3.5-inch, for SAS / SATA or 8x 2.5-inch for SAS/SATA/SSD optional; 3 x 5.25/1.6-inch accessible bays |
Capacity | Up to 8.0 TB |
HDD Suitability | SSD SATA, 3 Gb/s, 64 GB, SLC, 2.5", enterprise; SSD SATA, 3 Gb/s, 32 GB, SLC, 2.5", enterprise; HDD SATA, 6 Gb/s, 500 GB, 7200 rpm, 3.5", economic; HDD SATA, 6 Gb/s, 250 GB, 7200 rpm, 3.5", economic; HDD SATA, 3 Gb/s, 500 GB, 7200 rpm, 3.5", business critical; HDD SATA, 3 Gb/s, 500 GB, 7200 rpm, 2.5", business critical; HDD SATA, 3 Gb/s, 320 GB, 5400 rpm, 2.5", economic; HDD SATA, 3 Gb/s, 250 GB, 7200 rpm, 3.5", economic; HDD SATA, 3 Gb/s, 250 GB, 7200 rpm, 2.5", business critical; HDD SATA, 3 Gb/s, 160 GB, 7200 rpm, 3.5", economic; HDD SATA, 3 Gb/s, 160 GB, 5400 rpm, 2.5", economic; HDD SATA, 3 Gb/s, 2 TB, 7200 rpm, 3.5", business critical; HDD SATA, 3 Gb/s, 1 TB, 7200 rpm, 3.5", business critical; HDD SATA, 3 Gb/s, 1 TB, 7200 rpm, 2.5", business critical; HDD SAS, 6 Gb/s, 900 GB, 10k rpm, 2.5", enterprise; HDD SAS, 6 Gb/s, 600 GB, 15k rpm, 3.5", enterprise; HDD SAS, 6 Gb/s, 600 GB, 10k rpm, 2.5", enterprise; HDD SAS, 6 Gb/s, 450 GB, 15k rpm, 3.5", enterprise; HDD SAS, 6 Gb/s, 450 GB, 10k rpm, 2.5", enterprise; HDD SAS, 6 Gb/s, 300 GB, 15k rpm, 3.5", enterprise; HDD SAS, 6 Gb/s, 300 GB, 15k rpm, 2.5", enterprise; HDD SAS, 6 Gb/s, 300 GB, 10k rpm, 2.5", enterprise; HDD SAS, 6 Gb/s, 146 GB, 15k rpm, 2.5", enterprise; HDD SAS, 6 Gb/s, 73 GB, 15k rpm, 2.5", enterprise |
SATA Controller | Intel® 3420 Ibex Peak PCH Platform Control Hub, 2 ports used for accessible drives 4 port for internal SATA HDDs with RAID 0, 1, 10 for Windows and Linux; |
RAID Controller | Integrated RAID 0/1 or RAID 5/6 controller for SAS base units (option, occupies one PCIe slot). |
Supported OS | Microsoft® Hyper-V™ Server 2008 R2; Microsoft® Windows Server® 2008 R2 Datacenter; Microsoft® Windows Server® 2008 R2 Enterprise; Microsoft® Windows Server® 2008 R2 Standard; Microsoft® Windows Server® 2008 R2 Foundation; Microsoft® Windows® Web Server 2008 R2; Microsoft® Windows® Small Business Server 2011 Premium Add-On; Microsoft® Windows® Small Business Server Standard 2011; Microsoft® Windows® Server 2008 Enterprise; Microsoft® Windows® Server 2008 Standard; Microsoft® Windows® Small Business Server 2008 Standard; Microsoft® Windows® Small Business Server 2008 Premium; Microsoft® Windows Server® 2003 Enterprise Edition; Microsoft® Windows Server® 2003 Standard Edition; Microsoft® Windows Server® 2003 Web Edition; VMware vSphere™ 5.0 Embedded; VMware vSphere™ 5.0; VMware vSphere™ 4.1; VMware vSphere™ 4.1 Embedded; VMware vSphere™ 4.1 Installable; VMware vSphere™ 4.0; VMware vSphere™ 4.0 Embedded; VMware vSphere™ 4.0 Installable; Novell® SUSE Linux Enterprise Server 11; Novell® SUSE Linux Enterprise Server 10; Novell® SUSE Linux Enterprise Server 10 with XEN; Red Hat® Enterprise Linux 6; Red Hat® Enterprise Linux 5; Red Hat® Enterprise Linux 5 with XEN; Citrix® XenServer® |
USB Port(s) | 10 x USB 2.0 (3x front, 4x rear, 3x internal) |
PCI Slot(s) | PCI-Express 2.0 x1 (mech. x4) 2 x short; PCI-Express 2.0 x4 (mech. x8) 1 x Low profile ready, full height, long 3,3 V; PCI-Express 2.0 x8 2 x short 3,3V; PCI-slots 1 x PCI 32/33 MHz, 1x long, 5V |
Serial Ports | 1 x serial RS-232-C, usable for iRMC or system or shared, 1x Optional Additional RS-232-C |
LAN Socket(s) | 1 x Gbit/s Ethernet |
Bandwidth | GbE |
Graphics / GPU | 1 x VGA |
Standard | 1 year, On-site Service - depending on country. |
Optional | 7x24, Onsite Response Time: 4h |
T1507SF030DE; T1507SX040IN
