Fujitsu PRIMERGY BX2560 M2 Dual Socket Blade Server
Universal server blade that delivers a balance of value and performance
[BX2560M2]
The FUJITSU Server PRIMERGY BX2560 M2 is a dual-socket server blade that further extends the capabilities of the Fujitsu blade ecosystem.
Availability: In stock
Details
Part No. | BX2560M2 |
---|---|
Manufacturer | Fujitsu |
End of Life? | No |
Height | 21 |
Width | 4.5 |
Depth | 52 |
Weight [Kg] | 7.00 |
CPU Socket(s) | 1 - 2 x Intel® Xeon® E5-2600v4 processor |
Compatible CPU(s) | E5-2603v3 (6C/6T, 1.60GHz, TLC:15MB, Turbo:No, 6.4GT/s, Mem:1600MHz, 85W); E5-2609v3 (6C/6T, 1.90GHz, TLC:15MB, Turbo:No, 6.4GT/s, Mem:1600MHz, 85W); E5-2620v3 (6C/12T, 2.40GHz, TLC:15MB, Turbo:2.60GHz, 8.0GT/s, Mem:1866MHz, 85W); E5-2623v3 (4C/8T, 3.00GHz, TLC:10MB, Turbo:3.30GHz, 8.0GT/s, Mem:1866MHz, 105W); E5-2630Lv3 (8C/16T, 1.80GHz, TLC:20MB, Turbo:2.10GHz, 8.0GT/s, Mem:1866MHz, 55W); E5-2630v3 (8C/16T, 2.40GHz, TLC:20MB, Turbo:2.60GHz, 8.0GT/s, Mem:1866MHz, 85W); E5-2637v3 (4C/8T, 3.50GHz, TLC:15MB, Turbo:3.60GHz, 9.6GT/s, Mem:2133MHz, 135W); E5-2640v3 (8C/16T, 2.60GHz, TLC:20MB, Turbo:2.80GHz, 8.0GT/s, Mem:1866MHz, 90W); E5-2643v3 (6C/12T, 3.40GHz, TLC:20MB, Turbo:3.60GHz, 9.6GT/s, Mem:2133MHz, 135W); E5-2650Lv3 (12C/24T, 1.80GHz, TLC:30MB, Turbo:2.10GHz, 9.6GT/s, Mem:2133MHz, 65W); E5-2650v3 (10C/20T, 2.30GHz, TLC:25MB, Turbo:2.60GHz, 9.6GT/s, Mem:2133MHz, 105W); E5-2660v3 (10C/20T, 2.60GHz, TLC:25MB, Turbo:2.90GHz, 9.6GT/s, Mem:2133MHz, 105W); E5-2667v3 (8C/16T, 3.20GHz, TLC:20MB, Turbo:3.40GHz, 9.6GT/s, Mem:2133MHz, 135W); E5-2670v3 (12C/24T, 2.30GHz, TLC:30MB, Turbo:2.60GHz, 9.6GT/s, Mem:2133MHz, 120W); E5-2680v3 (12C/24T, 2.50GHz, TLC:30MB, Turbo:2.90GHz, 9.6GT/s, Mem:2133MHz, 120W); E5-2683v3 (14C/28T, 2.00GHz, TLC:35MB, Turbo:2.50GHz, 9.6GT/s, Mem:2133MHz, 120W); E5-2690v3 (12C/24T, 2.60GHz, TLC:30MB, Turbo:3.10GHz, 9.6GT/s, Mem:2133MHz, 135W); E5-2695v3 (14C/28T, 2.30GHz, TLC:35MB, Turbo:2.80GHz, 9.6GT/s, Mem:2133MHz, 120W); E5-2697v3 (14C/28T, 2.60GHz, TLC:35MB, Turbo:3.10GHz, 9.6GT/s, Mem:2133MHz, 145W); E5-2698v3 (16C/32T, 2.30GHz, TLC:40MB, Turbo:2.80GHz, 9.6GT/s, Mem:2133MHz, 135W); E5-2699v3 (18C/36T, 2.30GHz, TLC:45MB, Turbo:2.80GHz, 9.6GT/s, Mem:2133MHz, 145W); |
Memory Slot(s) | 16 (4 channels per CPU with 2 slots each) |
Memory Capacity | 1024 GB |
Drive Bays | 2 x 2.5-inch hot-plug PCIe/SAS/SATA SSD or 2x 2.5-inch hot-plug SAS/SATA HDD |
SATA Controller | Intel® C610 |
RAID Controller | RAID 0/1 for internal SAS/ SATA drives |
RAID Options | Fujitsu PRAID EM400i, SAS 12G RAID HDD module, 12 Gbit/s, RAID level: 0, 1, 10, 5, 50, 6, 60, 1024 MB Cache, Optional FBU (based on LSI SAS3108) Fujitsu PRAID CM400i, SAS 12G RAID HDD module, 12 Gbit/s, RAID level: 0, 1, 10, No FBU support (based on LSI SAS3108) |
Supported OS | Microsoft® Hyper-V Server 2012 R2; Microsoft® Windows Server® 2012 R2 Datacenter; Microsoft® Windows Server® 2012 R2 Standard; Microsoft® Windows Storage Server 2012 R2 Standard; Microsoft® Hyper-V Server 2012; Microsoft® Windows Server® 2012 Datacenter; Microsoft® Windows Server® 2012 Standard; Microsoft® Windows Storage Server 2012 Standard; Microsoft® Windows Server® 2008 R2 Datacenter; Microsoft® Windows Server® 2008 R2 Enterprise; Microsoft® Windows Server® 2008 R2 Standard; VMware vSphere™ 6.0; VMware vSphere™ 5.5; VMware vSphere™ 5.1 Embedded; VMware vSphere™ 5.1; SUSE® Linux Enterprise Server 12; SUSE® Linux Enterprise Server 11; Red Hat® Enterprise Linux 7; Red Hat® Enterprise Linux 6; Citrix® XenServer® |
USB Port(s) | USB 2.0 ports 4 (4x USB via special cable) // USB 3.0 ports 2 (1x USB at the front side+ 1x USB intern) |
PCI Slot(s) | PCI-Express 3.0 x8 // 2 x BX900 Mezzanine card |
LAN Socket(s) | 2 x 10 Gbit/s or 4 x 1Gbit/s via Midplane to Ethernet Connection Blade |
LAN Controller(s) | Emulex OCl14102. 2 x 10Gbit/s, 2 or 4 x 1Gbit/s Ethernet depending on installed Connection Blade. in 10Gbit/s mode CNA functionality with: - up to 8 physical function per port - optional one storage function (FCoE or iSCSI) with full offload PXE-Boot via |
Standard | 3 years onsite warranty |
Optional | Globally available in major business areas: 9x5, Next Business Day Onsite Response Time 9x5, 4h Onsite Response Time 24x7, 4h Onsite Response Time |
