Fujitsu PRIMERGY BX920 S4 Dual Socket Server Blade
Universal dual socket server blade with high computing and I/O performance in a small form factor
[BX920S4]
More Image(s)
The Fujitsu Server PRIMERGY BX920 S4 is a dual-socket server blade which offers the ideal balance of performance and cost-efficiency. It provides breakthrough server blade economics for essential enterprise workloads with the latest Intel® Xeon® processor E5-2400v2 product family, 768GB of memory, two hot-plug hard disk drives and flexible networking options via the onboard dual-channel 10Gbit/s Ethernet Converged Network Adapter.
Availability: In stock
Details
| Part No. | BX920S4 |
|---|---|
| Manufacturer | Fujitsu |
| End of Life? | No |
| Preceeded By | BX920 S3 |
| Rack Units | 1 |
| Height | 210 |
| Width | 45 |
| Depth | 500 |
| Weight [Kg] | 5.75 |
| CPU Socket(s) | 1 or 2 |
| Compatible CPU(s) | Intel® Xeon® processor E5-2400 v2 product family |
| Max CPU Clk Spd | Up to 3.2 GHz |
| CPU Cache | Up to 12 MB L3 per CPU |
| Max # Thread(s) | Up to 12 per CPU |
| Max # Core(s) | Up to 6 per CPU |
| Memory Capacity | 4 GB - 768 GB, DIMM (DDR3) registered |
| Drive Bays | 2 x 2.5-inch hot-plug SAS/SATA |
| Capacity | 3.6 TB |
| HDD Suitability | HDD SATA, 1 TB, 2.5-inch; HDD SATA, 250 GB, 2.5-inch; HDD SATA, 500 GB, 2.5-inch; HDD SAS, 146 GB, 2.5-inch; HDD SAS, 300 GB, 2.5-inch; HDD SAS, 450 GB, 2.5-inch; HDD SAS, 600 GB, 2.5-inch; HDD SAS, 1 TB, 2.5-inch; HDD SAS, 500 GB, 2.5-inch; HDD SAS, 1.2 TB, 2.5-inch; HDD SAS, 300 GB, 2.5-inch; HDD SAS, 450 GB, 2.5-inch; HDD SAS, 600 GB, 2.5-inch; HDD SAS, 900 GB, 2.5-inch; SSD SAS, 1.6 TB, 2.5-inch; SSD SAS, 200 GB, 2.5-inch; SSD SAS, 400 GB, 2.5-inch; SSD SAS, 800 GB, 2.5-inch; SSD SATA, 100 GB, 2.5-inch; SSD SATA, 200 GB, 2.5-inch; SSD SATA, 400 GB, 2.5-inch; SSD SATA, 800 GB, 2.5-inch; HDD SAS, 1.8 TB, 2.5-inch; HDD SAS, 1.2 TB, 2.5-inch; HDD SAS, 300 GB, 2.5-inch; HDD SAS, 600 GB, 2.5-inch; HDD SAS, 900 GB, 2.5-inch |
| RAID Controller | Integrated SAS RAID 0/1 for HDD´s |
| RAID Options | SAS RAID HDD module, 6 Gbit/s, Fujitsu, RAID level: 0, 1, 10, No BBU support (based on LSI SAS2208); SAS RAID HDD module, 6 Gbit/s, Fujitsu, RAID level: 0, 1, 10, 5, 50, 6, 60, 512 MB Cache, Optional BBU (based on LSI SAS2208) |
| Supported OS | Microsoft® Microsoft® Hyper-V™ Server 2008 R2; Microsoft® Windows Server® 2008 R2 Datacenter; Microsoft® Windows Server® 2008 R2 Enterprise; Microsoft® Windows Server® 2008 R2 Standard; Microsoft® Windows® Small Business Server 2011 Premium Add-On; Microsoft® Windows® Small Business Server Standard 2011; Microsoft® Windows® Server 2008 Enterprise; Microsoft® Windows® Server 2008 Standard; Microsoft® Windows Server® 2003 Enterprise Edition; Microsoft® Windows Server® 2003 Standard Edition; VMware vSphere™ 5.0 Embedded, 5.0, 4.1, 4.1 Embedded, 4.1 Installable, 4.0, 4.0 Embedded, 4.0 Installable; Novell® SUSE Linux Enterprise Server 11, 10, 10 with XEN; Red Hat® Enterprise Linux 6, 5, 5 with XEN; Citrix® XenServer® |
| USB Port(s) | 4 x USB at the front via special cable |
| PCI Slot(s) | PCI-Express 2.0 x8 (2 x BX900 Mezzanine Card) |
| Serial Ports | 1 x RS232 (9-pin) at the front via special cable |
| LAN Socket(s) | 2 x Intel® 82575, 2 x 10/100/1000 Mbit/s Ethernet, Intel® VT-c (includes I/OAT, VMDq) |
| LAN Controller(s) | Intel® 82575 |
| Bandwidth | 1 GbE |
| Standard | 3yr Onsite Service |
| Optional | 7x24, Onsite Response Time: 4h - For locations outside of EMEA please contact us. |
