Fujitsu PRIMERGY RX300 S8 Dual Socket Rack Server

Part No.	rx300s8
Manufacturer	Fujitsu
End of Life?	No
Preceeded By	RX300 S7
Rack Units	2 RU
Height	86.9
Width	482.6
Depth	445
Weight [Kg]	25.00
Specification	CB RoHS (Restriction of hazardous substances) WEEE (Waste electrical and electronical equipment)
CPU Socket(s)	1 - 2 x Intel® Xeon® processor E5-2600 v2 product family
Compatible CPU(s)	Intel® Xeon® E5-2650Lv2 (10C/20T, 1.70GHz, TLC: 25MB, 8.0 GT/s, Mem: 1600 MHz, 70W); Intel® Xeon® E5-2630Lv2 (6C/12T, 2.40GHz, TLC: 15MB, 7.2 GT/s, Mem: 1600 MHz, 60W); Intel® Xeon® E5-2660v2 (10C/20T, 2.20GHz, TLC: 25MB, 8.0 GT/s, Mem: 1866 MHz, 95W); Intel® Xeon® E5-2670v2 (10C/20T, 2.50GHz, TLC: 25MB, 8.0 GT/s, Mem: 1866 MHz, 115W); Intel® Xeon® E5-2680v2 (10C/20T, 2.80GHz, TLC: 25MB, 8.0 GT/s, Mem: 1866 MHz, 115W); Intel® Xeon® E5-2690v2 (10C/20T, 3.00GHz, TLC: 25MB, 8.0 GT/s, Mem: 1866 MHz, 130W); Intel® Xeon® E5-2695v2 (12C/24T, 2.40GHz, TLC: 30MB, 8.0 GT/s, Mem: 1866 MHz, 115W); Intel® Xeon® E5-2697v2 (12C/24T, 2.70GHz, TLC: 30MB, 8.0 GT/s, Mem: 1866 MHz, 130W); Intel® Xeon® E5-2603v2 (4C/4T, 1.80GHz, TLC: 10MB, 6.4 GT/s, Mem: 1333 MHz, 80W); Intel® Xeon® E5-2609v2 (4C/4T, 2.50GHz, TLC: 10MB, 6.4 GT/s, Mem: 1333 MHz, 80W); Intel® Xeon® E5-2637v2 (4C/8T, 3.50GHz, TLC: 15MB, 8.0 GT/s, Mem: 1866 MHz, 130W); Intel® Xeon® E5-2620v2 (6C/12T, 2.10GHz, TLC: 15MB, 7.2 GT/s, Mem: 1600 MHz, 80W); Intel® Xeon® E5-2630v2 (6C/12T, 2.60GHz, TLC: 15MB, 7.2 GT/s, Mem: 1866 MHz, 80W); Intel® Xeon® E5-2643v2 (6C/12T, 3.50GHz, TLC: 25MB, 8.0 GT/s, Mem: 1866 MHz, 130W); Intel® Xeon® E5-2640v2 (8C/16T, 2.00GHz, TLC: 20MB, 7.2 GT/s, Mem: 1600 MHz, 95W); Intel® Xeon® E5-2650v2 (8C/16T, 2.60GHz, TLC: 20MB, 8.0 GT/s, Mem: 1866 MHz, 95W); Intel® Xeon® E5-2667v2 (8C/16T, 3.30GHz, TLC: 25MB, 8.0 GT/s, Mem: 1866 MHz, 130W);
Max CPU Clk Spd	Up to 3.5 GHz
CPU Cache	Up to 30 MB per CPU
Max # Thread(s)	Up to 24 per CPU
Max # Core(s)	Up to 12 per CPU
Memory Slot(s)	24 (12 DIMMs per CPU, 4 channels with 3 slots per channel) DIMM DDR3
Memory Capacity	4 GB - 1536 GB
Memory Expansion	Advanced ECC; Memory Scrubbing; SDDC (Chipkill™); Rank sparing memory support; Memory Mirroring support
Drive Bays	6x 3.5" or 8x 2.5", or 12x 3.5" or 16x 2.5"
HDD Suitability	SSD SATA; SSD SAS; PCIe SSD; HDD SATA; HDD SAS
SATA Controller	Intel® C600, 1 x SATA channel for ODD
RAID Controller	4 port for internal 3G SATA and SAS (as upgrade option with SAS enabling key) for HDDs with RAID 0/1/10 or SAS LTO device (Intel C600)
RAID Options	RAID 5/6 Ctrl., SAS/SATA 6 Gbit/s, LSI LSI MegaRAID SAS 9286CV-8e, 8 ports ext. RAID level: 0, 1, 10, 5, 50, 6, 60, 1 GB, Optional FBU (based on LSI SAS2208) RAID 5/6 Ctrl., SAS/SATA 6 Gbit/s, Fujitsu RAID Ctrl SAS 6G 5/6 512MB (D2616), 8 ports int. RAID level: 0, 1, 10, 5, 50, 6, 60, 512 MB Cache, Optional BBU (based on LSI SAS2108) RAID 5/6 Ctrl., SAS/SATA 6 Gbit/s, Fujitsu RAID Ctrl SAS 6G 1GB (D3116C), 8 ports int. RAID level: 0, 1, 10, 5, 50, 6, 60, 1 GB, Optional FBU (based on LSI SAS2208) RAID 0/1 Ctrl., SAS/SATA 6 Gbit/s, Fujitsu RAID Ctrl SAS 6G 0/1 (D2607), 8 ports int. RAID level: 0, 1, 10, No BBU support
Supported OS	Microsoft Windows Server; Hyper-V; VMware vSphere; RHEL; Novell SuSE; Citrix Xenserver;
USB Port(s)	10 x USB 2.0 (2x front, 4x rear, 2x internal for backup devices, 1x USB stick, 1x uSSD)
PCI Slot(s)	5x LP PCIe Gen 3.0 x8; 2x LP PCIe Gen 3.0 x16 (2nd CPU Required)
Serial Ports	1 x serial RS-232-C, usable for iRMC or system or shared
LAN Socket(s)	2 x Gbit/s Ethernet (RJ45) with upgrade options for additional 2x1 Gbit/s (RJ45), 4x 1 Gbit/s (RJ45) or 2x 10 Gbit/s (SFP+)
LAN Controller(s)	Intel® Ethernet Controller I350, 2 x 10/100/1000 Mbit/s Ethernet (I/O acceleration), Modular integrated on-board LAN
Graphics / GPU	2 x VGA (thereof 1x front optional)
Standard	3 years Onsite Service (depending on country)
Optional	9x5, Next Business Day Onsite Response Time 9x5, 4h Onsite Response Time 24x7, 4h Onsite Response Time
