PRIMERGY TX140 S1: the expandable SME allrounder. It is ideal forSME or branch customers looking for a classic file, print, mail, or database server, with high scalability and record-setting performance per watt. As the company evolves, so too does the TX140 S1. Storing up to 8TB of data, the TX140 S1 can easily handle large files. At a later stage, the TX140 S1 can be included in a rack cabinet with dedicated storage systems. From here, customers can fully take advantage of the extensive connectivity options, Intel® Xeon® E3 series performance, and high serviceability via the optional front service LAN port. The TX140 S1: an excellent long-term investment.
Availability: In stock
Details
PRIMERGY TX tower servers are ideal for use in SMEs or branch offices. They increase operational efficiency by providing rock solid, record-breaking, energy efficient performance. That performance is built on 20-years of pioneering work in Green IT. As a customer, you benefit from a reduction in your organization’s environmental impact and lower running costs. The reliability is proven by testing the machines through 5000 boot cycles – far more than other vendors do. PRIMERGY TX servers are also easy to manage via the PRIMERGY ServerView Suite, reducing IT admin workload and costs. Plus, tower to rack conversion kits are available for most TX systems, ensuring investment protection.
Main Features
- The Intel® Xeon® processor E3 family-based platform and Fujitsu’s engineering capabilities give you excellent performance with low energy consumption (CSCI Gold).
- High performance and energy efficiency
- Up to 8TB of storage possible
- Whatever you need you can store it: databases, pictures, large files...storage - no problem!
- 2x 1Gigabit LAN as standard and 3.5-inch (max.4) or 2.5-inch (max.8) hot-plug hard disks
- High availability to keep your business going - non-stop!
- Optional tower to rack conversion kit and extensive connectivity options.
- The TX140 S1 grows as your company grows, making it an excellent long-term investment.
- The onboard remote management controller (iRMC S3), and the optional service LAN, makes it easier to service your TX140 S1.
- High manageability and serviceability - saving you time.
| Part No. | T1401SC010IN |
|---|---|
| Manufacturer | Fujitsu |
| Height | 444 or 220 mm |
| Width | 205 or 482 mm |
| Depth | 584 or 570 mm |
| Weight [Kg] | 28.00 |
| CPU Socket(s) | 1 x Intel® Core™ i3 processor / Intel® Pentium® processor / Intel® Xeon® processor E3 series |
| Compatible CPU(s) | Intel® Core™ i3-2100 processor (2C/4T, 3.10 GHz, TLC: 3 MB, Turbo: No, 1333 MHz, 65 W)
Intel® Core™ i3-2120 processor (2C/4T, 3.30 GHz, TLC: 3 MB, Turbo: No, 1333 MHz, 65 W)
Intel® Pentium® processor G620 (2C/2T, 2.60 GHz, TLC: 3 MB, Turbo: No, 1066 MHz, 65 W)
Intel® Xeon® processor E3-1220 (4C/4T, 3.10 GHz, TLC: 8 MB, Turbo: 3.40 GHz, 1333 MHz, 80 W); Intel® Xeon® processor E3-1230 (4C/8T, 3.20 GHz, TLC: 8 MB, Turbo: 3.60 GHz, 1333 MHz, 80 W); Intel® Xeon® processor E3-1240 (4C/8T, 3.30 GHz, TLC: 8 MB, Turbo: 3.70 GHz, 1333 MHz, 80 W); Intel® Xeon® processor E3-1260L (4C/8T, 2.40 GHz, TLC: 8 MB, Turbo: 3.30 GHz, 1333 MHz, 45 W); Intel® Xeon® processor E3-1270 (4C/8T, 3.40 GHz, TLC: 8 MB, Turbo: 3.80 GHz, 1333 MHz, 80 W); Intel® Xeon® processor E3-1280 (4C/8T, 3.50 GHz, TLC: 8 MB, Turbo: 3.90 GHz, 1333 MHz, 95 W) |
| Max CPU Clk Spd | Up to 3.30 GHz |
| CPU Cache | 3 or 8 MB |
| Max # Thread(s) | 2, 4 or 8 per CPU |
| Max # Core(s) | 2 or 4 per CPU |
| Memory Slot(s) | 4 |
| Memory Capacity | 32 GB |
| Drive Bays | 4x 3.5-inch, for SAS / SATA or 8x 2.5-inch for SAS/SATA optional; 3 x 5.25/1.6-inch |
| Capacity | Up to 8.0 TB |
| HDD Suitability | SSD SATA, 3 Gb/s, 64 GB, SLC, hot-plug, 2.5", enterprise; HDD SATA, 6 Gb/s, 500 GB, 7200 rpm, hot-plug, 3.5", economic; HDD SATA, 6 Gb/s, 250 GB, 7200 rpm, hot-plug, 3.5", economic; HDD SATA, 3 Gb/s, 500 GB, 7200 rpm, hot-plug, 3.5", business critical; HDD SATA, 3 Gb/s, 500 GB, 7200 rpm, hot-plug, 2.5", business critical; HDD SATA, 3 Gb/s, 320 GB, 5400 rpm, hot-plug, 2.5", economic; HDD SATA, 3 Gb/s, 250 GB, 7200 rpm, hot-plug, 2.5", business critical; HDD SATA, 3 Gb/s, 160 GB, 7200 rpm, hot-plug, 3.5", economic; HDD SATA, 3 Gb/s, 160 GB, 5400 rpm, hot-plug, 2.5", economic; HDD SATA, 3 Gb/s, 2 TB, 7200 rpm, hot-plug, 3.5", business critical; HDD SATA, 3 Gb/s, 1 TB, 7200 rpm, hot-plug, 3.5", business critical; HDD SATA, 3 Gb/s, 1 TB, 7200 rpm, hot-plug, 2.5", business critical; HDD SAS, 6 Gb/s, 900 GB, 10k rpm, hot-plug, 2.5", enterprise; HDD SAS, 6 Gb/s, 600 GB, 15k rpm, hot-plug, 3.5", enterprise; HDD SAS, 6 Gb/s, 600 GB, 10k rpm, hot-plug, 2.5", enterprise; HDD SAS, 6 Gb/s, 450 GB, 15k rpm, hot-plug, 3.5", enterprise; HDD SAS, 6 Gb/s, 450 GB, 10k rpm, hot-plug, 2.5", enterprise; HDD SAS, 6 Gb/s, 300 GB, 15k rpm, hot-plug, 3.5", enterprise; HDD SAS, 6 Gb/s, 300 GB, 15k rpm, hot-plug, 2.5", enterprise; HDD SAS, 6 Gb/s, 300 GB, 10k rpm, hot-plug, 2.5", enterprise; HDD SAS, 6 Gb/s, 146 GB, 15k rpm, hot-plug, 2.5", enterprise; HDD SAS, 6 Gb/s, 146 GB, 10k rpm, hot-plug, 2.5", enterprise; HDD SAS, 6 Gb/s, 73 GB, 15k rpm, hot-plug, 2.5", enterprise |
| SATA Controller | Intel® C200, 2 ports used for accessible drives 4 port for internal SATA HDDs with RAID 0, 1, 10 for Windows and Linux; |
| RAID Controller | Integrated RAID 0/1 or RAID 5/6 controller for SAS base units (option, occupies one PCIe slot). |
| RAID Options | RAID 5/6 Ctrl., HDD SAS 6 Gb, LSI , 8 ports ext.
RAID level: 0, 1, 10, 5, 50, 6, 60, 512 MB Cache, Optional BBU (based on LSI SAS2108); Integrated RAID 5/6 Ctrl., HDD SAS 6 Gb, Fujitsu , 8 ports int. RAID level: 0, 1, 10, 5, 50, 6, 60, 512 MB Cache, Optional BBU (based on LSI SAS2108); Integrated RAID 0/1 Ctrl., SAS/SATA 6 Gb, Fujitsu , 8 ports int. RAID level: 0, 1, 10, No BBU support (based on LSI SAS2008); Integrated RAID 0/1 Ctrl., SAS/SATA 3 Gb, 8 ports int. RAID level: 0, 1, 1E, No BBU support (based on LSI 1068e); Integrated RAID 0/1 Ctrl., SAS/SATA 3 Gb, 4 ports int. RAID level: 0, 1, 1E, No BBU support (based on LSI 1064e) |
| Supported OS | Microsoft® Hyper-V™ Server 2008 R2; Microsoft® Windows Server® 2008 R2 Datacenter; Microsoft® Windows Server® 2008 R2 Enterprise; Microsoft® Windows Server® 2008 R2 Standard; Microsoft® Windows Server® 2008 R2 Foundation; Microsoft® Windows® Web Server 2008 R2; Microsoft® Windows® Small Business Server 2011 Premium Add-On; Microsoft® Windows® Small Business Server Standard 2011; Microsoft® Windows® Server 2008 Datacenter; Microsoft® Windows® Server 2008 Enterprise; Microsoft® Windows® Server 2008 Standard; Microsoft® Windows® Web Server 2008; Novell® SUSE Linux Enterprise Server 11; Novell® SUSE Linux Enterprise Server 10; Red Hat® Enterprise Linux 6; Red Hat® Enterprise Linux 5 |
| USB Port(s) | 10 x USB 2.0 (2x front, 6x rear, 2x internal; the 2 internal ports cannot be used in parallel) |
| PCI Slot(s) | 1x PCI-Express 2.0 x1 (mech. x4); 1x PCI-Express 2.0 x4 (mech. x8); 1x PCI-Express 2.0 x16; 1x PCI 32/33 MHz, 1x long, 5V |
| Serial Ports | 2x 9-pin RS-232 serial ports |
| LAN Controller(s) | Intel® 82574L + Intel® 82579LM onboard, 2 x 10/100/1000 Mbit/s Ethernet (TCP/IP acceleration), iSCSI and PXE-Boot via LAN, WoL for Intel® 82574L only. |
| Graphics / GPU | 1 x VGA (15-pin) |
| Standard | 1 year, On-site Service - depending on country. |
| Optional | 7x24, Onsite Response Time: 4h |
Ideal server for SMEs or branch infrastructure where the main focus is on expandability and redundancy. Supports up to Intel(R) Xeon(R) processor 3400 series. Tower or Rack variant; up to 8 2.5" hard disks; server management controller onboard.
