Oracle Netra SPARC T3-1 Server
CUTTING EDGE THROUGHPUT, NETRA SPARC CARRIER-GRADE RACK SERVER
[286800]
Details
Based on SPARC T3 processor, this carrier-grade, NEBS Level 3 certified and ETSI compliant Netra SPARC T3-1 server combines cutting-edge performance with the ruggedness and reliability of the Sun Netra server family. The system supports up to 16 CPU cores doubling the number of compute threads when compared with the previous generation Sun Netra T5220 in a compact 2RU enclosure.
The system offers a large memory footprint with 16 DIMM slots making it ideally suited for memory-intensive applications. Storage connectivity bandwidth is also doubled from the previous generation server with the upgrade to SAS-2 interfaces. For even more flexibility, the Netra SPARC T3-1 server supports four internal disk drives with DVD-RW, five highbandwidth PCIe 2.0 and integrates four GbE ports to provide connectivity for high speed, high-bandwidth networking. Redundant hot-swappable AC or DC power supplies and hotpluggable hard disk drives enhance the system’s uptime. The Netra SPARC T3-1 will be offering longer lifecycle than commercial servers.
| Part No. | 286800 |
|---|---|
| Manufacturer | Sun Oracle |
| End of Life? | Yes |
| Succeeded By | Netra SPARC T4-1 |
| Rack Units | 2 U |
| Height | 87.1 mm |
| Width | 445 mm |
| Depth | 526 mm |
| Weight [Kg] | 18.60 |
| CPU Socket(s) | 1 |
| Compatible CPU(s) | SPARC T3 (16 Core) |
| Max CPU Clk Spd | 1.65 GHz |
| CPU Cache | 6 MB Level 2 Integrated |
| Max # Thread(s) | 128 |
| Max # Core(s) | 16 |
| Memory Slot(s) | 16 |
| Memory Capacity | 128 GB |
| Drive Bays | 4x SAS-2 |
| RAID Options | RAID Levels 0,1 |
| Supported OS | Oracle Solaris 10 |
| USB Port(s) | 4x USB 2.0 |
| PCI Slot(s) | 5x PCIe |
| LAN Socket(s) | 4x 10/100/1000 Mbps Ethernet; 2x Optional 10 GbE XAUI Connections |
| Graphics / GPU | 1x HD15 VGA Port |
In addition, the Netra SPARC T3-1 server is offered with the Sun Integrated Lights Out Manager (ILOM), which enables simple remote monitoring and management from anywhere on the network. Finally, the Netra SPARC T3-1 supports Oracle Solaris 10, which will provide full binary compatibility with earlier Netra SPARC servers, preserving investment.
