The Oracle Database Appliance is a new way to take advantage of the world's most popular database—Oracle Database 11g—in a single, easy-to-deploy and manage system. It's a complete package of software, server, storage, and networking that's engineered for simplicity; saving time and money by simplifying deployment, maintenance, and support of database workloads.
Availability: In stock
Details
- A fully integrated and redundant system of software, servers, storage and networking in a single box that delivers high-availability database services for a wide range of homegrown and packaged online transaction processing (OLTP) and data warehousing applications
- Saves up to 2000 hours of labor over a three year period with simple deployment, maintenance, and support of database workloads, all supported by a single vendor—Oracle
- Pay-As-You-Grow software licensing allows you to quickly scale from 2 processor cores to 24 processor cores without incurring the costs and downtime usually associated with hardware upgrades
- Allows businesses to consolidate OLTP and data warehousing databases up to 4 terabytes in size, making it ideal for midsize companies and departmental systems
| Part No. | 495410 |
|---|---|
| Manufacturer | Sun Oracle |
| Rack Units | 4 U |
| Height | 175.1 |
| Width | 482.6 |
| Depth | 782.0 |
| Weight [Kg] | 72.60 |
| Specification | • Safety: UL/CSA 60950-1 2nd Ed, EN60950-1:2006 2nd Ed +A11:2009,
IEC60950-1:2005 CB Scheme with all country differences • RFI/EMI: FCC CFR 47 Part 15 Subpart B Class A, EN 55022:2006+A1:2007 Class A, EN 61000-3-2:2006, EN 61000-3-3:1995+A1:2001+A2:2002, ETSI EN 300 386 V1.4.1 (2008) • Immunity: EN 55024:1998+A1:2001:+A2:2003 |
| CPU Socket(s) | 4 per System (2 per Server Node) |
| Compatible CPU(s) | Intel® Xeon X5675 Processors |
| Max CPU Clk Spd | 3.06 Ghz (3.46 Ghz Turbo) |
| CPU Cache | L1: 32 KB Instruction, 32 KB Data L2: 256 KB Unified L3: 12 MB Shared Inclusive *per CPU |
| Max # Thread(s) | 12 per CPU |
| Max # Core(s) | 6 per CPU |
| Memory Capacity | 96 GB |
| Drive Bays | 20x 3.5" 600 GB 15krpm SAS HDDs per system. (Storage) 4x 3.5" 73 GB SAS SSDs per system. (Database redo logs) 2x rear accessible, 2.5" 500 GB 7.2krpm SATA HDDs (mirrored) per Server Node. (OS) |
| Capacity | 12 TB raw (triple-mirrored), 4 TB useable |
| HDD Suitability | SAS |
| USB Port(s) | 1x Internal 4 GB USB thumb drive per server node, 2x rear USB 2.0 ports |
| PCI Slot(s) | 4x PCIe 2.0 slots, eight lane electrical/mechanical per server node.
|
| LAN Socket(s) | 2x 1 GbE ports (onboard) per server node. |
| Graphics / GPU | VGA 2-D embedded graphics controller |
| Resolution (Native) | Support for resolutions of up to 1,600 × 1,200 × 16 bits @ 60 Hz (1,024 × 768 when viewed remotely via Oracle Integrated Lights Out Manager [Oracle ILOM] RKVMS) |
