Fujitsu ETERNUS DX200 S4 Disk Storage System

The all-in-one storage system for SMBs or subsidiaries

[DX200 S4]

More Image(s)

The scalable and unified Fujitsu Storage ETERNUS DX200 S4 delivers enterprise-class functionality to small and medium-sized companies and subsidiaries with an excellent price/performance ratio.
Availability: In stock

For details on how to purchase the Fujitsu ETERNUS DX200 S4 Disk Storage System, please click the button below to send us your details and brief requirements. We can then quote you accordingly.

Details

The scalable and unified Fujitsu Storage ETERNUS DX200 S4 delivers enterprise-class functionality to small and medium-sized companies and subsidiaries with an excellent price/performance ratio.

It is the perfect solution when consolidating data for server virtualization, e-mail, databases and business applications as well as centralized file services.

Simple, intuitive system management, highly flexible connectivity and the option of field upgrades to higher system classes significantly reduce operational and migration costs.

The ETERNUS DX family architecture lets customers benefit from software options, such as thin provisioning, automatic storage tiering, transparent failover and quality of service management even as early as the entry-level class. This all contributes to better business support.

Maximum utilization and consolidation

  • Comprehensive scalability ready for future needs
  • Outstanding benchmark results with ultra-low latency
  • Unified SAN and NAS access drive system utilization improving ROI
  • Flexible combination of flash and disk media for a broader scope of deployments
  • ETERNUS SF Express management suite included at no extra cost

Business Continuity around the clock

  • Replication and Storage Cluster to avoid planned or unplanned downtimes
  • Transparent failover for 100% data insurance and non-stop operations
  • Intelligent snapshot functionality for backup
  • System availability of 99.9999%

Automated Quality-of-Service

  • Control of applications priorities according to business needs
  • Automation of monitoring and adjustment
  • Minimization of admin efforts
  • Guaranteed service levels

Selective use of deduplication / compression

  • Decide on application label which option fits best
  • Don't compromise applications with performance SLA's
  • Capacity savings in hybrid configurations
Manufacturer Fujitsu
Part No. DX200 S4
End of Life? No
Preceeded By DX200 S3
Width 482
Height 88
Depth 670
Weight [Kg] 35.00
Rack Units 2 or 4
Memory Capacity 64
Drive Bays 264
Capacity HDD: 2640 TB
SSD: 4055 TB
HDD Suitability 2.5-inch, SAS, 15,000 rpm (900 GB / 600 GB / 300 GB);
2.5-inch, SAS, 10,000 rpm (1.8 TB / 1.2 TB / 900 GB / 600 GB / 300 GB);
2.5-inch, SAS (self-encrypting), 10,000rpm (1.2TB);
2.5-inch, Nearline SAS, 7,200 rpm (2 TB / 1 TB);
2.5-inch, SSD (15.36TB / 7.68TB / 3.84 TB / 1.92 TB / 960GB / 400 GB);
2.5-inch, SSD (self-encrypting) (1.92 TB);
3.5-inch, Nearline SAS, 7,200 rpm (10 TB / 8 TB / 6 TB / 4 TB / 2 TB);
3.5-inch, Nearline SAS (self-encrypting), 7,200 rpm (4 TB);
3.5-inch, SSD (3.84TB / 1.92TB / 960GB / 400GB);
3.5-inch, SSD (self-encrypting) (1.92TB);
HDDE, SAS, 10,000 rpm (1.2 TB);
HDDE, Nearline SAS, 7,200 rpm (10 TB / 8 TB / 6 TB / 4 TB / 2 TB);
HDDE, SSD (3.84TB / 1.92TB);
HDDE, Nearline SAS(self-encrypting), 7,200 rpm (4TB)
Max. No. of Drive Enclosure(s) Max. 10
Max. LUN Capacity 128 TB
Max. No. of LUNs 8192
No. of Snapshots 2048 Max.
Cache 800 GB
Host Interface / Link Speeds Fibre Channel (32Gbit/s, 16Gbit/s, 8Gbit/s);
iSCSI (10 Gbit/s [10GBase-SR, 10GBase-CR, 10GBase-T], 1 Gbit/s);
Ethernet (10 Gbit/s, 1 Gbit/s);
SAS (12Gbit/s)
No. of Host Interfaces 2/4/8 ports [FC, iSCSI, SAS], 8/16 ports [Ethernet(1Gbit/s)], 4/8 ports [Ethernet(10Gbit/s)]
Max. No. of Host(s) 1024
Supported OS Microsoft Windows Server 2016;
Microsoft Windows Server 2012, 2012 R2;
Microsoft Windows Server 2008, 2008 R2;
Solaris11 (11/11 or later);
Solaris 10;
Red Hat Enterprise Linux 7;
Red Hat Enterprise Linux 6;
Red Hat Enterprise Linux 5;
VMware® vSphere 6.0, 6.5;
VMware® vSphere 5/ 5.1/ 5.5;
Microsoft Windows Server 2016 Hyper-V;
Microsoft Windows Server 2012 Hyper-V, 2012 R2 Hyper-V;
Microsoft Windows Server 2008 Hyper-V, 2008 R2 Hyper-V;
Hyper-V 2.0
LAN Socket(s) Ethernet (1000 Base-T / 100 Base-TX / 10 Base-T)
Remote Management Web-based graphical user interface, CLI (Command Line Interface), ETERNUS SF
RAID Controller 0, 1, 1+0, 5, 5+0, 6
Standard 3 years onsite warranty
Optional X - Available in major business areas:
9x5, Next Business Day Onsite Response Time
9x5, 4h Onsite Response Time (depending on country)
24x7, 4h Onsite Response Time (depending on country)
Fujitsu ETERNUS DX200 S4 Disk Storage System
