Dell PowerEdge R450 Server
[R450 ]
Details
Deliver performance at scale with the Dell EMC PowerEdge portfolio
Modern compute platforms from Dell EMC easily scale and leverage key technologies to maximize application performance. The PowerEdge R450 is built on a scalable architecture that provides the choice and flexibility to optimize performance and density
- Scale compute resources with 3rd Generation Intel® Xeon® Scalable processors that offer up to 1.50x performance gains over previous generation Cascade Lake. Ice Lake CPUs scale up to 40cores per CPU
- Flexible storage with up to 10 x 2.5 SAS/SATA/SSD with up to 4 NVMe PCIe SSD’s or 4 x 3.5
- Free up storage with boot optimized M.2 SSDs.
Intuitive systems management with intelligent automation
The Dell EMC OpenManage™ portfolio helps deliver peak efficiency for PowerEdge servers, delivering intelligent, automated management of routine tasks. Combined with unique agent-free management capabilities, the R640 is simply managed, freeing up time for high profile projects
- Simplify management of your servers with OpenManage Essentials, a 1:many console that automates all phases of lifecycle management: deployment, updates, monitoring, and maintenance.
- Use Quick Sync 2, a wireless module, and the OpenManage Mobile app for at-server management, to configure or troubleshoot in the data center, and to receive alerts when you’re on the go.
Rely on PowerEdge with built-in security
Every PowerEdge server is made with a cyber-resilient architecture, building security into all parts of a server’s lifecycle. The R450 uses these new security features so you can reliably and securely deliver the right data to where your customers are, no matter where they are. Dell EMC consider each part of system security, from design to end of life, to ensure trust and deliver worry-free, secure systems.
- Rely on a secure supply chain that protects servers from factory to the data center.
- Maintain data safety with cryptographically signed firmware packages and Secure Boot.
- Prevent unauthorized or malicious change with Server Lockdown.
- Wipe all data from storage media including hard drives, SSDs and system memory quickly and securely with System Erase.
| Part No. | R450 |
|---|---|
| Manufacturer | Dell Technologies |
| End of Life? | No |
| Preceeded By | r440 |
| Height | 42.8mm |
| Width | 434mm |
| Depth | 714.62mm |
| Weight [Kg] | 17.60 |
| CPU Socket(s) | 2 |
| Compatible CPU(s) | Up to two 3rd Generation Intel® Xeon® Scalable processors |
| Max # Core(s) | up to 28 cores per processor |
| Memory Slot(s) | 16 DDR4 DIMM slots, Supports RDIMM /LRDIMM |
| Memory Capacity | speeds up to 2933MT/s, 1TB max |
| Drive Bays | Front drive bays: Up to 10 x 2.5” SAS/SATA (HDD/SSD) with up to 4 NVMe SSD max 76.8TB or up to 4 x 3.5 SAS/SATA HDD max 64TB Optional DVD-ROM, DVD+RW |
| SATA Controller | RAID (SWRAID) S140 |
| RAID Options | Boot Optimized Storage Subsystem: HWRAID 2 x M.2 SSDs 120GB, 240 GB External PERC (RAID): H840 External HBAs (non-RAID): 12 Gbps SAS HBA |
| Supported OS | Canonical® Ubuntu® Server LTS Citrix® Hypervisor Microsoft Windows Server® LTSC with Hyper-V Red Hat® Enterprise Linux SUSE® Linux Enterprise Server VMware® ESXi |
| USB Port(s) | Front ports: 1 x Dedicated iDRAC Direct USB, 1 x USB 2.0, 1 x USB 3.0 (Optional), 1 x Video ,Rear ports: 2 x USB 3.0, 1 x Video |
| PCI Slot(s) | Up to 2 x PCIe Gen 3 slots all x16 |
| Serial Ports | 1 x Serial |
| LAN Socket(s) | 2 x 1GbE LOM + (optional) LOM Riser 2 x 1GbE or 2x 10GbE SFP+ or 2 x 10GbE BaseT |
